| Type of Product | Earth Leakage Breaker |
| Model No | GK58WNX3P40AF100 |
| Rated Breaking Capacity (kA) | (AC100/200V)5 |
| Frame (AF) | 50 |
Type of Product |
Earth Leakage Breaker |
Model No |
GK58WNX3P40AF100 |
Rated Breaking Capacity (kA) |
(AC100/200V)5 |
Frame (AF) |
50 |
Rated Sensitivity Current (mA) |
100 |
Protective Function |
Protection against earth leakage, overload, short circuit, and single/three-phase neutral line loss |
Monotaro ID |
70046308 |
Rated Current (A) |
40 |
Country of Origin |
Japan |
Rated Insulation Voltage (V) |
AC100/200 |
Reverse Connection |
Impossible |
Terminal Structure |
Wire clamp terminal M5 |
Name of Manufacturer/Packer/Importer |
Nitto Kogyo Co., Ltd. |
Import Country |
Direct Import from Japan |
Compatible Cable |
to 22 mm² |
No. of Poles / Elements |
3P2E |
Operating Time (s) |
Within 0.1 |
Detachment Method |
[Overcurrent] Completely electromagnetic type |
Appearance |
White color |
Pack of |
1 Piece |
