| Type of Product | Plug-in Unit with Earth Leakage Breaker |
| Model No | GE53CXPS3P20AF30 |
| Dimension | 75×146×80 mm |
| Phase / Wire Type | 3Φ・1Φ3W・1Φ2W |
Type of Product |
Plug-in Unit with Earth Leakage Breaker |
Model No |
GE53CXPS3P20AF30 |
Dimension |
75×146×80 mm |
Phase / Wire Type |
3Φ・1Φ3W・1Φ2W |
Overcurrent Tripper Type |
Complete electromagnetic type |
Rated Voltage (V) |
Use: AC100-200 |
Protective Function |
Protects against electric leakage, overload, and short-circuit motors |
Monotaro ID |
68935338 |
Rated Current (A) |
(Reference ambient temperature 40°C) 20 |
Country of Origin |
Japan |
Applicable crimp terminal |
R2-5 to CB22-5S |
Applicable Standard |
JIS C 8201-2-2 Ann2 |
Reverse Connection |
Not possible (It can only be used as a reverse-connectable type for grid-connected applications such as solar power generation systems.) |
Name of Manufacturer/Packer/Importer |
Nitto Kogyo Co., Ltd. |
Import Country |
Direct Import from Japan |
Specifications |
Ampere Frame: 50AF |
No. of Poles / Elements |
3P3E |
High-Speed Operation Time (sec) |
Within 0.1 |
Rated Breaking Capacity (kA) (100VAC) |
JIS：5, JIS：5 |
High-Speed Rated Sensitivity Current (mA) |
30 |
Structure |
Terminal power supply side: Plug-in terminal, Terminal power supply side: Crimp terminal M5 |
Pack of |
1 Piece |
