| Type of Product | Earth Leakage Breaker |
| Sensitivity | [Movement] Equivalent to seismic intensity 5 or higher (operates at 250 gal cycle 0.3 s, 0.5 s, 0.7 s ・ does not operate at 80 gal cycle 0.3 s, 0.5 s, 0.7 s and 250 gal cycle 0.1 s) |
| Model No | GK103WN-MGU3P100AF30 |
| Rated Breaking Capacity (kA) | 5 |
Type of Product |
Earth Leakage Breaker |
Sensitivity |
[Movement] Equivalent to seismic intensity 5 or higher (operates at 250 gal cycle 0.3 s, 0.5 s, 0.7 s ・ does not operate at 80 gal cycle 0.3 s, 0.5 s, 0.7 s and 250 gal cycle 0.1 s) |
Model No |
GK103WN-MGU3P100AF30 |
Rated Breaking Capacity (kA) |
5 |
Frame (AF) |
100 |
Mass (Kg) |
0.66 |
Rated Voltage (V) |
AC100 / AC200 (AA) |
Rated Sensitivity Current (mA) |
30 |
Monotaro ID |
73550164 |
Rated Current (A) |
100 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Nitto Kogyo Co., Ltd. |
Import Country |
Direct Import from Japan |
Specifications |
[Interruption time] 3 minutes / 1 minute / immediate switching |
No. of Poles / Elements |
3P3E |
Alarm Output |
Alarm is output while the buzzer sounds and the lamp blinks red. Open collector DC30V 20mA |
Display |
[Alarm] Buzzer: Sound / Lamp: Red flashing, [Electric shock cut] When the breaker is turned on, the lamp lights orange |
Reset |
[Input] No-voltage a contact DC5V 0.1A |
Pack of |
1 Piece |
