Rated Sensitivity Current (mA)
Rated Current (A)
Model No
View
View
View
View
| Type of Product | Earth Leakage Breaker |
| No. of Pole | 3P3E |
| Model No | BJWA312532 |
| Rated Voltage | AC 100-200 V dual use 50 kA |
Type of Product |
Earth Leakage Breaker |
No. of Pole |
3P3E |
Model No |
BJWA312532 |
Rated Voltage |
AC 100-200 V dual use 50 kA |
Terminal Shape |
For crimp terminal |
Operating Time |
Within 0.1 |
Phase / Wire Type |
3Φ3 W, 1Φ3 W |
Mass (Kg) |
1.8 |
Type |
BJWA-225 |
Rated Sensitivity Current (mA) |
30 |
Monotaro ID |
61357505 |
Tightening Torque (Nm) |
8 to 13 |
Rated Current (A) |
125 |
Country of Origin |
Japan |
Applicable crimp terminal |
(Nichifu) 14-8, 22-8, 38-8, 60-8 (included) |
Earth Leakage Indication |
Mechanical button |
Reverse Connection |
Possible |
Frame |
225 AF |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Import Country |
Direct Import from Japan |
Specifications |
For installation inside a box, with terminal cover, compatible with lightning surges and harmonics (inverters, etc.) |
External Dimensions (width x depth x height) (mm) |
105 x 165 (249 including terminal cover) x 68 (95 including handle) |
Quantity |
One |
Capacity |
Motor: AC200 V 30 kW |
