| Type of Product | Earth Leakage Breaker |
| No. of Pole | 3P3E |
| Model No | BJW33509K |
| Terminal Shape | Bar terminal |
Type of Product |
Earth Leakage Breaker |
No. of Pole |
3P3E |
Model No |
BJW33509K |
Terminal Shape |
Bar terminal |
Operating Time |
Within 0.1 Seconds |
Phase / Wire Type |
3Φ3W, 1Φ3W |
Rated Breaking Capacity (kA) |
25(AC415V)/50(AC200 V)/50(AC100V) |
Overcurrent Tripper Type |
Thermal / Electromagnetic |
Mass (Kg) |
4.8 |
Type |
BJW-400 |
Rated Voltage (V) |
AC100-200-415 shared |
Rated Sensitivity Current (mA) |
100/200/500 switching |
Protective Function |
Overcurrent, Short Circuit, Earth Leakage |
Monotaro ID |
38180694 |
Tightening Torque (Nm) |
40-50 |
Rated Current (A) |
350 |
Part No |
BJW33509K |
Country of Origin |
Japan |
Application |
For mounting in a box |
Terminal Screw |
M12 |
Applicable crimp terminal |
(Nichifu) 200-12, 250-12, 325-12S |
Earth Leakage Indication |
Mechanical Button |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Import Country |
Direct Import from Japan |
Specifications |
Terminal Cover Included |
