| Type of Product | Earth Leakage Breaker |
| No. of Pole | 2P2E |
| Model No | BKWM243C |
| Rated Voltage | AC 100-200 V dual use, AC 100 V 2.5 kA, AC 200 V 2.5 kA |
Type of Product |
Earth Leakage Breaker |
No. of Pole |
2P2E |
Model No |
BKWM243C |
Rated Voltage |
AC 100-200 V dual use, AC 100 V 2.5 kA, AC 200 V 2.5 kA |
Terminal Shape |
Full up terminal |
Operating Time |
Within 0.1 seconds |
Mass (Kg) |
0.4 |
Type |
BKWM-30C |
Rated Sensitivity Current (mA) |
30 |
Monotaro ID |
61360978 |
Tightening Torque (Nm) |
2 to 2.5 |
Rated Current (A) |
4 |
Country of Origin |
Japan |
Standard |
JIS agreement type |
Earth Leakage Indication |
Mechanical button |
Reverse Connection |
Possible |
Frame |
30 AF |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Import Country |
Direct Import from Japan |
Specifications |
Compatible with lightning surges and harmonics (inverters, etc.) |
External Dimensions (width x depth x height) (mm) |
50x96x60 (75.6 including handle) |
Operation Ambient Temperature (°C) |
-10 to 60 |
Quantity |
One |
Connectable Stranded Wire (mm²) |
2 to 14 |
DIN Rail Type |
Can be installed |
