| Type of Product | Earth Leakage Breaker |
| No. of Pole | 2P2E |
| Model No | BJW253 |
| Terminal Shape | Full-up terminal (for both electric wire and crimp terminals) |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Earth Leakage Breaker |
No. of Pole |
2P2E |
Model No |
BJW253 |
Terminal Shape |
Full-up terminal (for both electric wire and crimp terminals) |
Operating Time |
Within 0.1 Seconds |
Phase / Wire Type |
1Φ2W |
Rated Breaking Capacity (kA) |
2.5 |
Overcurrent Tripper Type |
Electromagnetic |
Mass (Kg) |
0.4 |
Type |
BJW-30 |
Rated Voltage (V) |
AC100-200 |
Rated Sensitivity Current (mA) |
30 |
Protective Function |
Overcurrent, Overload (Motor), Short Circuit, Leakage |
Monotaro ID |
38179766 |
Tightening Torque (Nm) |
2-2.5 |
Rated Current (A) |
5 |
Part No |
BJW253 |
Country of Origin |
Japan |
Application |
For mounting in a box |
Motor Capacity (kW) |
0.4(200 V) |
Terminal Screw |
M5 |
Earth Leakage Indication |
Mechanical Button |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Import Country |
Direct Import from Japan |
Specifications |
With Open/Close Flap Small Terminal Cover, Also Serves As Motor Protection |
