| Type of Product | Earth Leakage Breaker |
| No. of Pole | 3P3E |
| Model No | BJWA3504 |
| Rated Voltage | AC 100-200 V dual use 2.5 kA |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Earth Leakage Breaker |
No. of Pole |
3P3E |
Model No |
BJWA3504 |
Rated Voltage |
AC 100-200 V dual use 2.5 kA |
Terminal Shape |
Full-up terminal (for both electric wire and crimp terminals) |
Operating Time |
Within 0.1 seconds |
Phase / Wire Type |
3Φ3 W, 1Φ3 W |
Mass (Kg) |
0.5 |
Type |
BJWA-50 |
Rated Sensitivity Current (mA) |
100 |
Monotaro ID |
61358808 |
Tightening Torque (Nm) |
2 to 2.5 |
Rated Current (A) |
50 |
Country of Origin |
Japan |
Applicable crimp terminal |
(Nichifu) 14-5, CB22-5S |
Earth Leakage Indication |
Mechanical button |
Reverse Connection |
Possible |
Frame |
50 AF |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Import Country |
Direct Import from Japan |
Specifications |
For installation inside a box, with terminal cover, compatible with lightning surges and harmonics (inverters, etc.) |
External Dimensions (width x depth x height) (mm) |
70x96(106 including terminal cover)x52(67.6 including handle) |
Quantity |
One |
Connectable Stranded Wire (mm²) |
2 to 14 |
Capacity |
Motor: AC200 V 11 kW |
