| Type of Product | Earth Leakage Breaker |
| No. of Pole | 3P3E |
| Model No | BJWN36092 |
| Rated Voltage | AC 100/200 V only (AA) 25 kA |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Earth Leakage Breaker |
No. of Pole |
3P3E |
Model No |
BJWN36092 |
Rated Voltage |
AC 100/200 V only (AA) 25 kA |
Terminal Shape |
For crimp terminal |
Phase / Wire Type |
1Φ3 W |
Mass (Kg) |
1 |
Type |
BJWN-125 |
Rated Sensitivity Current (mA) |
100/200/500 |
Monotaro ID |
61357094 |
Tightening Torque (Nm) |
5.5 to 7 |
Rated Current (A) |
60 |
Country of Origin |
Japan |
Applicable crimp terminal |
(Nichifu) 14-8, 22-8 (included) |
voltage rating (V) |
Overvoltage: 130 (-10 to 5V) |
Reverse Connection |
Impossible |
Display Type |
Electric leakage/overvoltage: Mechanical button |
Frame |
125 AF |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Import Country |
Direct Import from Japan |
Specifications |
For installation inside a box, with terminal cover, compatible with lightning surges and harmonics (inverters, etc.) |
External Dimensions (width x depth x height) (mm) |
75 x 130 (180 including terminal cover) x 68 (95 including handle) |
Quantity |
One |
Lead Wire Length (mm) |
Overvoltage detection: 0.5 mm² xL500 |
