| Type of Product | Earth Leakage Breaker |
| No. of Pole | 3P3E |
| Model No | BKWN33509 |
| Rated Voltage | AC 100/200 V only (AA) 50 kA |
Type of Product |
Earth Leakage Breaker |
No. of Pole |
3P3E |
Model No |
BKWN33509 |
Rated Voltage |
AC 100/200 V only (AA) 50 kA |
Terminal Shape |
Bar terminal |
Operating Time |
(At the time of earth leakage) Within 0.1, (At the time of phase failure) Within 1 |
Mass (Kg) |
4.8 |
Type |
BKWN-400 |
Rated Sensitivity Current (mA) |
100/200/500 |
Monotaro ID |
61363455 |
Rated Current (A) |
350 |
Country of Origin |
Japan |
Applicable crimp terminal |
(Nichifu) 200-12, 250-12, 325-12S |
voltage rating (V) |
Overvoltage: 130 (-10 to 5V) |
Reverse Connection |
Impossible |
Display Type |
Electric leakage/open phase: Mechanical button |
Frame |
400 AF |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Import Country |
Direct Import from Japan |
Specifications |
Compatible with lightning surges and harmonics (inverters, etc.) |
External Dimensions (width x depth x height) (mm) |
140 x 257 (343 including bar) x 107 (135 including handle) |
Operation Ambient Temperature (°C) |
-10 to 60 |
Quantity |
One |
