| Type of Product | Earth Leakage Breaker |
| No. of Pole | 3P2E |
| Model No | BKWN3509S |
| Rated Voltage | AC 100/200 V only (AA) 10 kA |
Type of Product |
Earth Leakage Breaker |
No. of Pole |
3P2E |
Model No |
BKWN3509S |
Rated Voltage |
AC 100/200 V only (AA) 10 kA |
Terminal Shape |
Full up terminal |
Operating Time |
(During phase loss) Within 0.5, (During electrical leakage) Within 0.1 |
Mass (Kg) |
0.5 |
Type |
BKWN-50S |
Rated Sensitivity Current (mA) |
100/200/500 |
Monotaro ID |
61357417 |
Rated Current (A) |
50 |
Country of Origin |
Japan |
Applicable crimp terminal |
(Nichifu) 14-5, CB22-5S |
voltage rating (V) |
Overvoltage: 130±5 |
Reverse Connection |
Impossible |
Display Type |
Electric leakage/open phase: Mechanical button |
Frame |
50 AF |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Import Country |
Direct Import from Japan |
Specifications |
Lightning surge and harmonics (inverter, etc.) resistant, JIS standard type |
External Dimensions (width x depth x height) (mm) |
75 x 96 x 60 (75.6 including handle) |
Operation Ambient Temperature (°C) |
-10 to 60 |
Quantity |
One |
Connectable Stranded Wire (mm²) |
2 to 14 |
Wire Diameter |
Φ1.6 to 2.6 mm |
