| Type of Product | Earth Leakage Breaker |
| No. of Pole | 3P2E |
| Model No | BJWN3604 |
| Rated Voltage | AC 100/200 V only (AA) 5 kA |
Type of Product |
Earth Leakage Breaker |
No. of Pole |
3P2E |
Model No |
BJWN3604 |
Rated Voltage |
AC 100/200 V only (AA) 5 kA |
Terminal Shape |
Full up terminal |
Phase / Wire Type |
1Φ3 W |
Mass (Kg) |
0.5 |
Type |
BJWN-60 |
Rated Sensitivity Current (mA) |
100 |
Monotaro ID |
61359045 |
Tightening Torque (Nm) |
3 to 4 |
Rated Current (A) |
60 |
Country of Origin |
Japan |
Applicable crimp terminal |
(Nichifu) 14-6, CB22-6S |
voltage rating (V) |
Overvoltage: 130±5 |
Reverse Connection |
Impossible |
Display Type |
Electric leakage/overvoltage: Mechanical button |
Frame |
60 AF |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Import Country |
Direct Import from Japan |
Specifications |
For installation inside a box, with terminal cover, compatible with lightning surges and harmonics (inverters, etc.) |
External Dimensions (width x depth x height) (mm) |
70x96(106 including terminal cover)x52(67.6 including handle) |
Quantity |
One |
Connectable Stranded Wire (mm²) |
14 to 22 |
Lead Wire Length (mm) |
Overvoltage detection: 0.5 mm² xL500 |
