| Type of Product | Earth Leakage Breaker |
| Model No | GB-103KC 50A 30MA |
| Operating Time | (Maximum) 0.1 seconds |
| Rated Breaking Capacity (kA) | (AC 100 V) 5/2, (AC 200 V) 5/2 |
Type of Product |
Earth Leakage Breaker |
Model No |
GB-103KC 50A 30MA |
Operating Time |
(Maximum) 0.1 seconds |
Rated Breaking Capacity (kA) |
(AC 100 V) 5/2, (AC 200 V) 5/2 |
Frame (AF) |
100 |
Overcurrent Tripper Type |
Thermodynamic electromagnetic |
Mass (Kg) |
0.59 |
Type |
K series (distribution panel agreement type size) |
Rated Voltage (V) |
AC 100-AC 200 |
Rated Sensitivity Current (mA) |
30 |
Monotaro ID |
39209021 |
Rated Current (A) |
50 |
Terminal Type |
Crimp terminal method (crimp terminal included) |
Country of Origin |
Japan |
Connection Type |
Surface Type |
Reverse Connection |
Impossible |
Name of Manufacturer/Packer/Importer |
Tenpearl Industries Co., Ltd. |
Import Country |
Direct Import from Japan |
Dimension (mm) |
H98xW75xD79 (including handle) |
Rated Impulse Withstand Voltage (kV) |
6 |
Dimension B (Φmm) |
75 |
Dimension A (Φmm) |
98(156) |
Dimension d |
79 mm |
Dimension C |
60 mm |
No. of Poles / Elements |
3P3E |
Connectable Wire (mm2) |
(Maximum) 38 |
