| Type of Product | Earth Leakage Circuit Breaker |
| Model No | GB-3MEC 20A 15MA |
| Overcurrent Tripper Type | Fully electromagnetic |
| Mass (Kg) | 0.4 |
Type of Product |
Earth Leakage Circuit Breaker |
Model No |
GB-3MEC 20A 15MA |
Overcurrent Tripper Type |
Fully electromagnetic |
Mass (Kg) |
0.4 |
Type |
E series Economic type |
Rated Voltage (V) |
AC 100-AC 200 |
Rated Sensitivity Current (mA) |
15 |
Monotaro ID |
39206097 |
Rated Current (A) |
20 |
Terminal Type |
Wire clamp method (crimp terminals can be used) |
Country of Origin |
Japan |
Connection Type |
Surface Type |
Earth Leakage Indication |
Included |
Reverse Connection |
Impossible |
Name of Manufacturer/Packer/Importer |
Tenpearl Industries Co., Ltd. |
Import Country |
Direct Import from Japan |
Rated Impulse Withstand Voltage (kV) |
6 |
Dimension B (Φmm) |
70 |
Dimension A (Φmm) |
105(115) |
Dimension d |
67.5 mm |
Dimension C |
49 mm |
Connectable Wire (mm2) |
(Maximum) 22 |
