| Type of Product | Earth Leakage Circuit Breaker |
| Model No | 52NA4015 |
| Rated Breaking Capacity (kA) | ���JIS C 8222 Ann2(Icn) AC100/200V���2.5 |
| Frame (AF) | 50 |
Type of Product |
Earth Leakage Circuit Breaker |
Model No |
52NA4015 |
Rated Breaking Capacity (kA) |
���JIS C 8222 Ann2(Icn) AC100/200V���2.5 |
Frame (AF) |
50 |
Overcurrent Tripper Type |
Heat |
Mass (Kg) |
0.18 |
Type |
Earth leakage breaker |
Rated Sensitivity Current (mA) |
15 |
Monotaro ID |
72999651 |
Rated Current (A) |
40 |
Country of Origin |
Japan |
External dimensions (mm) |
88.5 |
Connection Type |
Surface Type |
Rated operating voltage (AC V) |
100/200���200 |
Earth Leakage Indication |
Yes (manual return) |
Reverse Connection |
Impossible |
Name of Manufacturer/Packer/Importer |
Tenpearl Industries Co., Ltd. |
Import Country |
Direct Import from Japan |
JIS Standard |
JIS C 8222 Ann2 |
No. of Poles / Elements |
2P2E |
Rated Breaking Capacity (kA) (200VAC) |
���JIS C 8222 Ann2(Icn)���2.5 |
Connectable Wire (mm2) |
Up to 14 |
Name |
Pearltect Earth Leakage Circuit Breaker |
Remark |
Flat handle |
External Dimensions / Height (mm) |
46.5, 56 (height to the handle) |
