| Type of Product | Circuit Breaker |
| No. of Pole | 2P |
| Model No | B-32KC 15A AL |
| Overcurrent Tripper Type | Thermodynamic electromagnetic |
Type of Product |
Circuit Breaker |
No. of Pole |
2P |
Model No |
B-32KC 15A AL |
Overcurrent Tripper Type |
Thermodynamic electromagnetic |
Mass (Kg) |
0.26 |
Type |
K series (distribution panel agreement type size) |
Monotaro ID |
39203656 |
Rated Current (A) |
15 |
Country of Origin |
Japan |
Reverse Connection |
Possible |
Frame |
30 AF |
No. of Elements |
2E |
Name of Manufacturer/Packer/Importer |
Tenpearl Industries Co., Ltd. |
Import Country |
Direct Import from Japan |
Specifications |
Surface type / wire holding method (crimp terminals can be used) |
Rated Impulse Withstand Voltage (kV) |
6 |
Dimension B (Φmm) |
50 |
Dimension A (Φmm) |
98(112) |
Dimension d |
79 mm |
Dimension C |
60 mm |
Rated Breaking Capacity (kA) (200VAC) |
(AV100/100/200/200V)5/2, (DC125V)0.7/- |
Connectable Wire (mm2) |
(Maximum) 22 |
Rated Working Voltage |
AV100・100/200・200V, DC125V |
