Ships within 25 days
View
View
View
View
| Type of Product | Earth Leakage Circuit Breaker |
| Model No | GB-2EA 20A 30MA |
| Rated Breaking Capacity (kA) | (Icn)(100/200VAC)1.5 |
| Overcurrent Tripper Type | Heat |
Type of Product |
Earth Leakage Circuit Breaker |
Model No |
GB-2EA 20A 30MA |
Rated Breaking Capacity (kA) |
(Icn)(100/200VAC)1.5 |
Overcurrent Tripper Type |
Heat |
Mass (Kg) |
0.18 |
Type |
E series Economic type |
Rated Voltage (V) |
AC 100-AC 100/AC 200-AC 200 |
Rated Sensitivity Current (mA) |
30 |
Monotaro ID |
39206002 |
Rated Current (A) |
20 |
Terminal Type |
Solderless terminal type (with washer) |
Country of Origin |
Japan |
Connection Type |
Surface Type |
Earth Leakage Indication |
Yes (manual return) |
Reverse Connection |
Possible |
Name of Manufacturer/Packer/Importer |
Tenpearl Industries Co., Ltd. |
Import Country |
Direct Import from Japan |
Dimension B (Φmm) |
68 |
Dimension A (Φmm) |
70 |
Dimension d |
57 mm |
Dimension C |
40 mm |
Connectable Wire (mm2) |
(Maximum) 8 |
