Ships within 19 days
View
View
View
View
| Type of Product | Earth Leakage Circuit Breaker |
| Model No | 103EC10W2LS |
| Frame (AF) | 100 |
| Overcurrent Tripper Type | Thermodynamic electromagnetic |
Type of Product |
Earth Leakage Circuit Breaker |
Model No |
103EC10W2LS |
Frame (AF) |
100 |
Overcurrent Tripper Type |
Thermodynamic electromagnetic |
Type |
Earth leakage breaker |
Rated Sensitivity Current (mA) |
100/200/500 |
Monotaro ID |
73006005 |
Rated Current (A) |
100 |
Suitable For |
[Compatible Accessories: Terminal Cover, Rear-Mounted Type (BTC)] Rear-mounted type included (for BTC-153EC 3P) |
Country of Origin |
Japan |
Connection Type |
Back side |
Rated operating voltage (AC V) |
100���200 |
Earth Leakage Indication |
Included |
Reverse Connection |
Possible |
Included Components |
Mounting screws (M4 x 70) x 2, terminal covers x 2, sealing plates x 2, hex bolts (M8 x 20, including nuts, etc.) x 6 |
Name of Manufacturer/Packer/Importer |
Tenpearl Industries Co., Ltd. |
Import Country |
Direct Import from Japan |
Specifications |
For motor protection |
Rated Impulse Withstand Voltage (kV) |
6(Uimp) |
No. of Poles / Elements |
3P3E |
Terminal |
Bar stud system |
Motor Capacity |
22 kW (AC 200 V) |
Name |
E Series (Economy Type) |
Remark |
This device is resistant to harmonics (such as inverters) and is immune to lightning impulses. |
Inertia Non-Operation Time |
0.15 sec |
