| Display | Large LCD display with backlight |
| Weight | 935 g (with batteries) |
| Type of Product | Earth Tester |
| Frequency | Measurement at 2,083 Hz, transposition at 50/60/128/2083 Hz |
Display |
Large LCD display with backlight |
Weight |
935 g (with batteries) |
Type of Product |
Earth Tester |
Frequency |
Measurement at 2,083 Hz, transposition at 50/60/128/2083 Hz |
Model No |
CA 6417 V2 |
Safety Rating |
CAT III 300V |
Dimension |
262 × 95 × 55 mm |
Measurement Range |
0.01Ω to 1200Ω |
Power Supply |
4 × AA (LR6) alkaline or NiMH batteries |
Item Code |
GROUND TESTER CA 6417 V2 |
Country of Origin |
India |
Battery Life |
~1,440 measurements (30 s each) |
Name of Manufacturer/Packer/Importer |
Atandra Energy Private Limited |
Current Measurement |
0.2 mA to 40 A |
Protection |
IP40 |
Jaw Opening |
Ø 35 mm |
Memory |
Up to 300 measurements |
Inductance |
10 μH to 500 μH (Loop Inductance) |
Loop Resistance |
0.01 Ω to 1,500 Ω |
Voltage Measurement |
0.1 V to 75 V |
