| Type of Product | Thin MP3 Playback Alarm |
| Model No | BSV-24NL-D |
| Protection Class | IP54 (Positive panel mounting, front only) |
| Monotaro ID | 60963315 |
Type of Product |
Thin MP3 Playback Alarm |
Model No |
BSV-24NL-D |
Protection Class |
IP54 (Positive panel mounting, front only) |
Monotaro ID |
60963315 |
Sound Pressure |
87 dB/m |
Mass (g) |
100 |
Material |
Case: Polycarbonate resin |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Patlite Corporation |
Rated Voltage (V) |
DC 12-24 |
Power Consumption (W) |
(Maximum) 3.5 |
Specifications |
No message recording (15 built-in alarm sounds), maximum playback time 520 seconds |
Body Color |
Off dark gray |
Mass (Kg) |
0.1±10% |
Operating Temperature Range |
-10 to +50℃ (85% or less humidity) |
Playback Channel |
4 (bit input) 15 (binary input) |
Allowable Voltage Range |
DC 10.8 to 26.4 V |
Trusco Part No. |
792-8521 |
Correction |
Supported transistor NPN |
Continuous Playback Time |
(Maximum) about 520 seconds |
