| Color | White gray |
| Voltage | 12/24 V DC |
| Type of Product | Electronic Sound Alarm |
| Model No | ST-25CS-DCW |
Color |
White gray |
Voltage |
12/24 V DC |
Type of Product |
Electronic Sound Alarm |
Model No |
ST-25CS-DCW |
Type |
Single type |
Monotaro ID |
2090785 |
Sound Pressure Level (dB) |
Up to 102 (1m forward) |
Inrush current (A) |
DC12V/12, DC24V/0.4 |
Material |
(Body) ASA resin, (Angle / nameplate) Stainless steel SUS, (Rear cover) Transparent polycarbonate resin |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Arrow & Harmony (Schneider Electric) |
Tone |
A/Flicker sound (beep-beep-beep...) standard, B/Flicker sound (high pitch) C/Peep-peep sound (peep-peep-peep...), D/Peep-peep sound (high pitch) E/Flicker sound (fast cycle), F /flicker sound (high pitch, fast cycle) G/beep sound (fast cycle), H/beep sound (high pitch, fast cycle) high) Playback number 1 note (set with the voice selector switch) |
Power Consumption (W) |
46087 |
Mass (Kg) |
1 |
Operating Temperature Range |
-20 to 50℃ |
Line Type |
VCT-F (Φ6.5) 0.75 mm² x 2 core |
Lead Wire Length (mm) |
500 |
Rated Output (W) |
2 |
Power Supply Voltage |
DC 12V/DC 24V |
Rated Time (minutes) |
Continuous |
