| Voltage | 200 V |
| Type of Product | Electric Power Digital Torque |
| Country of Origin | Japan |
| Square Drive Size | 25.4 |
Voltage |
200 V |
Type of Product |
Electric Power Digital Torque |
Country of Origin |
Japan |
Square Drive Size |
25.4 |
Name of Manufacturer/Packer/Importer |
TONE Co., Ltd. |
Pack of |
Each of 1 Pcs |
Product Code |
PDX302A |
Rotation Speed at No Load (min-1 rpm) |
3.5 |
Monotaro ID |
42856967 |
Maximum Power Consumption (w) |
1350 |
Mass (Kg) |
Straight type reaction force receiving: 1.6, L type reaction force receiving: 2.0 |
Maximum Current (A) |
7 |
Frequency (Hz) |
50/60 |
Included Components |
Straight type reaction force receiver (30SH): 1, L type reaction force receiver (30SLH): 1, Hexagon socket head set screw: 4, (-) Baby screwdriver (for torque setting dial adjustment): 1, (-) screwdriver: 1, Hexagonal L-shaped wrench (4mm): 1, Battery (AA alkaline battery): 4, microSD memory card (1 set): 1, Instruction manual: 1, Calibration certificate (with traceability system diagram): 1 , Metal case: 1 |
Number of Continuous Use |
About 1000 (about 85 hours) |
Operating Temperature / Humidity Range |
0 to 40 degrees, 80% RH or less (no condensation) |
Suitable Battery |
AA x 2 Alkaline batteries or rechargeable NiMH batteries |
Minimum Display |
2 to 3 |
Accuracy (%) |
± 4 (limited to attached reaction force) |
Memory Card |
microSD |
Torque Range (Nm) |
1000 to 3000 |
Import Country |
Direct Import from Japan |
