| Voltage | 100 V |
| Type of Product | Electric Power Digital Torque |
| Country of Origin | Japan |
| Square Drive Size | 38.1 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Voltage |
100 V |
Type of Product |
Electric Power Digital Torque |
Country of Origin |
Japan |
Square Drive Size |
38.1 |
Name of Manufacturer/Packer/Importer |
TONE Co., Ltd. |
Pack of |
Each of 1 Pcs |
Product Code |
PDX501A |
Rotation Speed at No Load (min-1 rpm) |
2 |
Monotaro ID |
42856976 |
Maximum Power Consumption (w) |
1350 |
Mass (Kg) |
Straight type reaction force receiving: 1.8, L type reaction force receiving: 2.3 |
Maximum Current (A) |
14 |
Frequency (Hz) |
50/60 |
Included Components |
Straight type reaction force receiver (50SH): 1, L type reaction force receiver (50SLH): 1, Hexagon socket set screw: 4, (-) Baby screwdriver (for torque setting dial adjustment): 1, (-) screwdriver: 1, Hexagonal L-shaped wrench (4mm): 1, Battery (AA alkaline battery): 4, microSD memory card (1 set): 1, Instruction manual: 1, Calibration certificate (with traceability system diagram): 1 , Metal case: 1 |
Number of Continuous Use |
About 1000 (about 85 hours) |
Operating Temperature / Humidity Range |
0 to 40 degrees, 80% RH or less (no condensation) |
Suitable Battery |
AA x 2 Alkaline batteries or rechargeable NiMH batteries |
Minimum Display |
3 to 4 |
Accuracy (%) |
± 4 (limited to attached reaction force) |
Memory Card |
microSD |
Torque Range (Nm) |
2000 to 5000 |
