| Type of Product | [Converter] Ethernet to optical fiber (multimode/single mode/SFP) |
| Model No | EKI-2541M-BE |
| Monotaro ID | 6563676 |
| Input Power | 12 to 48 V DC |
Type of Product |
[Converter] Ethernet to optical fiber (multimode/single mode/SFP) |
Model No |
EKI-2541M-BE |
Monotaro ID |
6563676 |
Input Power |
12 to 48 V DC |
Width (mm) |
95 |
Length (mm) |
140 |
Operating Temperature Range |
-10 to 60℃ |
RoHS Directive |
Correspondence |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Advantech Co., Ltd. |
Converter Type |
Ethernet to multimode fiber optic |
Thickness |
30 mm |
Transmission Speed |
100 Mbps |
Port Type |
1xRJ45 port, 1xSC fiber optic port |
Conform to |
【Wide Temperature Range】- |
Protection |
[Power line surge (EFT)] 3000 V DC |
Communication Protocol |
[Before conversion] Ethernet, [After conversion] Optical communication |
ESD Protection |
[Ethernet] 4000 VDC |
Dimensions (H x W x D) (mm) |
140x95x30 |
Various Certifications |
CE, FCC, Class A |
Type of Terminal Fitting |
DIN rail, wall |
Communication Standard |
[Network] Auto MDI / MDI-X compatible / Auto-negotiation compatible |
