| Type of Product | Pulse Counter |
| Model No | CNT-723 |
| Monotaro ID | 66273116 |
| Input Power | AC 100-240 V |
Type of Product |
Pulse Counter |
Model No |
CNT-723 |
Monotaro ID |
66273116 |
Input Power |
AC 100-240 V |
Input Method |
Single phase, A/B phase |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Atmosphere |
Surrounding area: No corrosive gases |
Name of Manufacturer/Packer/Importer |
COCO RESEARCH |
Storage Temperature/Humidity Range |
-10℃ to +60℃/85%RH or less (no condensation) |
Power Consumption (VA) |
30VA or less |
Operating Temperature / Humidity Range |
0℃ - +40℃/85%RH or less (no condensation) |
Specifications |
●RS-232C communication/flow control, Communication code, Connector, Communication data: RTS/CTS, ASCII, D-sub 9-pin male (use a cross cable to connect to the host), Setting changes, Count value reading●RS-232C communication/Communication method: Start-stop synchronization●RS-232C communication/Transmission format: Start bit 1 bit, stop bit 1 bit, data length 8 bits, no parity bit●RS-232C communication/Transmission speed: 9.6k/19.2k/38.4k/57.6k/115.2kbps●Isolation: Sensor power supply, Signal input/Analog output, Digital output/Power input●Analog: 3.5μs to ±5, ±10V |
