| Type of Product | Analog Input/Output |
| Model No | AIO-120802LN2-USB |
| Monotaro ID | 69014569 |
| Size | N type |
Type of Product |
Analog Input/Output |
Model No |
AIO-120802LN2-USB |
Monotaro ID |
69014569 |
Size |
N type |
No. Of Output |
8 points/16 points |
RoHS Directive |
Correspondence |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Number of Input Points |
8 points/16 points |
Series |
PC-HELPER USB type N |
Name of Manufacturer/Packer/Importer |
Contec Co., Ltd. |
Resolution |
ADC：12-bit, DAC：12-bit |
No. of Channels |
1-ch |
Output Range |
±10V； ±5V； 0 to 10V； 0 to 5V |
Input Range |
±10V； ±5V； ±2.5V； 0 to 10V |
voltage rating (V) |
(Input) 5DC-TTL, (Output) 5DC-TTL |
Memory |
Input: 1k Word, Output: 1k Word |
Update Rate |
12μsec (max.) |
Supported OS |
Windows 11 (64-bit)； Windows 10 IoT Enterprise LTSC 2021 (64-bit)； Windows 10 IoT Enterprise 2019 LTSC (64-bit)； Windows 10 IoT Enterprise LTSB 2016 (64-bit)； Windows 10 (64-bit)； Windows 10 (32-bit)； Windows 8.1 (64-bit)； Windows 8.1 (32-bit)； Windows 7 (64-bit)； Windows 7 (32-bit)； Windows Vista (64-bit)； Windows Vista (32-bit)； Windows XP (64-bit)； Windows XP (32-bit)； Windows 2000 (32-bit)； Windows Server 2008 (64-bit)； Windows Server 2008 (32-bit)； Windows Server 2003 (64-bit)； Windows Server 2003 (32-bit)； Linux |
Specifications |
USB, Two-way points: 16 points |
Suitable Connector |
5x 3.5mm pitch 10-pin 2-piece terminal blocks |
Circuit (input) |
Non-isolated TTL level input (positive logic) |
Response Speed |
5MHz, (input) 200nsec (max.), (output) 200nsec (max.) |
Sampling Speed |
5μsec/ch (max.) |
Counting Mechanism |
32-bit up |
