| Type of Product | Post with Base |
| Model No | B20B-XH-A(LF)(SN) |
| Monotaro ID | 34953527 |
| Suitable For | xHP-※ |
Type of Product |
Post with Base |
Model No |
B20B-XH-A(LF)(SN) |
Monotaro ID |
34953527 |
Suitable For |
xHP-※ |
Color |
Natural (white) |
Type |
Top type |
Material |
Brass, 66 nylon |
Standard |
Recognised E 60389 Certified LR 20812 J50014297 |
Rated Voltage (V) |
250 V AC/DC |
Rated Current (A) |
3 AC / DC, (When using AWG # 22) |
Dimension B (Φmm) |
52.4 |
No. of Pole |
20 |
Dimension A (Φmm) |
47.5 |
Withstand Voltage |
1000 VAC for 1 minute |
Operating Temperature Range |
-25 to +85℃ (including temperature rise during energization) |
Surface Treatment |
Copper-undercoated tin plating (reflow treatment) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Japan Solderless Terminals Mfg. Co., Ltd. |
Pack of |
10 Pcs |
Insulation Resistance (MOhm) |
1000 or more |
Contact Resistance (ohm) |
Initial: 10 mΩ or less After environmental test: 20 mΩ or less |
Specifications |
RoHS compliant product with clinch |
Wire Crimping Range (AWG#) |
30 to 22 |
Suitable Circuit Board Thickness (mm) |
1.6 |
