| Type of Product | Compact AC Solenoid |
| Model No | SAL-02 100V |
| Monotaro ID | 2025835 |
| Rated Voltage (V) | AC 100V |
Type of Product |
Compact AC Solenoid |
Model No |
SAL-02 100V |
Monotaro ID |
2025835 |
Rated Voltage (V) |
AC 100V |
Mass (g) |
81, (Movable iron core) 18 |
Rated Frequency (Hz) |
50/60 shared (2 leads) |
Insulation Type |
Class A insulation equivalent |
RoHS Directive |
Correspondence |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Insulation Resistance (MOhm) |
50 or more (DC500V) |
Withstand voltage (V / min) |
AC 1500 |
Specifications |
1 minute rated current |
Starting Current (A) |
1.5 |
Suction Power |
2.9 N [0.3 kgf] |
Stroke (mm) |
10 |
Acting Type |
Dual-use type |
Holding Current (A) |
0.6 |
Endurance Times |
300,000 times |
