| Type of Product | Triple 3-Input NAND Logic Gate |
| Maximum Operating Temperature | +125 °C |
| Country of Origin | US |
| Length | 8.75mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Triple 3-Input NAND Logic Gate |
Maximum Operating Temperature |
+125 °C |
Country of Origin |
US |
Length |
8.75mm |
Width |
4mm |
Height |
1.45mm |
Name of Manufacturer/Packer/Importer |
Nexperia |
Dimension |
8.75 x 4 x 1.45mm |
Pack of |
Each of 1 Piece |
Package Type |
SOIC |
Mounting Type |
Surface Mount |
Pin Count |
14 |
Minimum Operating Temperature |
-40 °C |
Maximum Operating Supply Voltage |
6 V |
Minimum Operating Supply Voltage |
2 V |
Manufacturer Model Number |
74HC10D,652 |
Maximum Propagation Delay Time @ Maximum CL |
16 ns @ 6 V, 19 ns @ 4.5 V, 95 ns @ 2 V |
Propagation Delay Test Condition |
50pF |
Logic Family |
HC |
Maximum Low Level Output Current |
5.2mA |
Maximum High Level Output Current |
-5.2mA |
Schmitt Trigger Input |
No |
Logic Function |
NAND |
