| Type of Product | Quad 2-Input NAND Schmitt Trigger Logic Gate |
| Maximum Operating Temperature | +125 °C |
| Input Type | Schmitt Trigger |
| Country of Origin | US |
Type of Product |
Quad 2-Input NAND Schmitt Trigger Logic Gate |
Maximum Operating Temperature |
+125 °C |
Input Type |
Schmitt Trigger |
Country of Origin |
US |
Length |
8.75mm |
Width |
4mm |
Height |
1.45mm |
Name of Manufacturer/Packer/Importer |
Nexperia |
Dimension |
8.75 x 4 x 1.45mm |
Pack of |
Each of 1 Piece |
Package Type |
SO |
Mounting Type |
Surface Mount |
Pin Count |
14 |
Minimum Operating Temperature |
-40 °C |
Output Type |
Single Ended |
Maximum Operating Supply Voltage |
3.6 V |
Minimum Operating Supply Voltage |
1.2 V |
Manufacturer Model Number |
74LVC00AD,112 |
Maximum Propagation Delay Time @ Maximum CL |
9.7 ns @ 50 pF |
Propagation Delay Test Condition |
50pF |
Logic Family |
74LVC |
Maximum Low Level Output Current |
24mA |
Maximum High Level Output Current |
-24mA |
Schmitt Trigger Input |
Yes |
Logic Function |
NAND |
