| Type of Product | Circuit Breaker |
| Model No | NE402AB2P300A |
| Monotaro ID | 45167647 |
| Rated Current (A) | 300 |
Type of Product |
Circuit Breaker |
Model No |
NE402AB2P300A |
Monotaro ID |
45167647 |
Rated Current (A) |
300 |
Applicable crimp terminal |
R60-12 to R325-12S/325-12 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Connection Type |
Back side |
Included Components |
Terminal cover, terminal screw, mounting screw, wood screw, ground barrier, sealing screw, terminal cover set screw |
Name of Manufacturer/Packer/Importer |
Nitto Kogyo Co., Ltd. |
Pack of |
1 Piece |
Rated Insulation Voltage (V) |
AC690 |
No. of Poles / Elements |
2P2E |
Reverse Connection |
Possible |
Frame (AF) |
400 |
Rated Breaking Capacity (kA) |
25(AC415), 50(AC200) |
Terminal Structure |
Bar terminal M12 |
JIS Standard |
JIS C 8201-2-1 Ann2 |
Overcurrent Tripper Type |
Thermal-electromagnetic |
