Ships within 25 days
View
View
View
View
| Type of Product | Circuit Breaker |
| Model No | GK108NA3P60AF30 |
| Monotaro ID | 45182076 |
| Type | Agreement type |
Type of Product |
Circuit Breaker |
Model No |
GK108NA3P60AF30 |
Monotaro ID |
45182076 |
Type |
Agreement type |
Rated Sensitivity Current (mA) |
(High-speed type) 30 |
Mass (Kg) |
0.53 |
Rated Voltage (V) |
AC100 / AC200 (AA) |
Rated Current (A) |
60 |
Dimensions A (mm) |
75 |
Applicable crimp terminal |
R5.5-5 to CB60-8 |
Dimensions B (mm) |
98 |
Dimensions C (mm) |
60 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Included Components |
Terminal cover, mounting screw, wood screw, sealing plate, rail holder, rail holder spring, crimp terminal |
Dimensions D (mm) |
78 |
Name of Manufacturer/Packer/Importer |
Nitto Kogyo Co., Ltd. |
Pack of |
1 Piece |
Protective Function |
Leakage / overload / short circuit / AA neutral line open phase protection |
Phase / Wire Type |
1Φ3W |
No. of Poles / Elements |
3P2E |
Reverse Connection |
Impossible |
Rated Breaking Capacity (kA) |
5 |
Terminal Structure |
M8 for crimp terminal |
Connectable Wire (mm2) |
60 |
Overcurrent Tripper Type |
Thermal-electromagnetic |
High-Speed Operation Time (sec) |
Within 0.1 |
