Ships within 19 days
Model No
No. of Pole
View
View
View
View
| Type of Product | Short-Circuit Plug |
| Model No | XJ8C-0611 |
| Monotaro ID | 39215066 |
| Standard | RoHS directive, UL standard (File No.E103202) |
Type of Product |
Short-Circuit Plug |
Model No |
XJ8C-0611 |
Monotaro ID |
39215066 |
Standard |
RoHS directive, UL standard (File No.E103202) |
Rated Voltage (V) |
AC300 |
Rated Current (A) |
2 |
Shape |
Short-circuit plug 2-row type (low profile) |
Dimension B (Φmm) |
5.08 |
No. of Pole |
6 |
Dimension A (Φmm) |
7.6 |
Contact Material |
Brass |
Withstand Voltage |
750 VAC, 1 min (leakage current 1 mA or less) |
Surface Treatment |
Nickel base gold plating (0.15 μm) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Insertion / Removal Durability (Times) |
50 |
Housing Material |
Glass-filled PBT resin (UL94V-0) / Black |
Total Insertion Force |
1.96N or less (with short-circuit dedicated plug) |
Total Removal Force |
0.39 or more (with short-circuit plug) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-55 to +105 (no freezing in the bass) |
Pack of |
10 Pcs |
Insulation Resistance (MOhm) |
10³ mohm or more (at 500 V DC) |
Contact Resistance (ohm) |
20 or less (20mV or less, 100mA or less) |
