Ships within 19 days
Number of Input/Output Points
Model No
View
View
View
View
| Type of Product | Digital I/O Slave |
| Model No | CRT1-MD16 |
| Monotaro ID | 46384021 |
| Type | Multi-Feed Type |
Type of Product |
Digital I/O Slave |
Model No |
CRT1-MD16 |
Monotaro ID |
46384021 |
Type |
Multi-Feed Type |
Mass (g) |
170 or less |
Withstand Voltage |
500 V AC (between isolated circuits) |
Power Supply Voltage |
Communication power supply: 14 to 26.4 DC I/O power supply: 20.4 to 26.4 DC (24 V DC -15 to +10%) |
Current Consumption (mA) |
Communication power supply: 35 or less (at 24 V DC power supply voltage), 60 or less (at 14 V DC power supply voltage) I/O power supply: Input 5 or less (at 24 V DC power supply voltage) Output 15 or less (at 24 V DC power supply voltage) |
Current (mA) |
Input/OFF current: 1.0 or less Output/leakage current: 0.1 or less |
Voltage |
Input/ON voltage: 15 DC V or more (between each input terminal) Input/OFF voltage: 5 DC or less (between each input terminal) Output/residual voltage: 1.2 or less (0.5 A DC, between each output terminal and G) |
Insulation Type |
Photocoupler insulation |
Ambient Humidity to Use |
25 to 85% (Non-Condensing) |
Storage Temperature |
-25 to +65℃ |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Noise Resistance |
Compliant with IEC61000-4-4 2 kV (power line) |
Terminal Fitting Type |
DIN Rail Mounting |
Display |
I / O / LED display (yellow) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Rated Output Current (A) |
0.5 / point, 2 / common |
Operation Ambient Temperature (°C) |
-10 to +55 |
Insulation Resistance (MOhm) |
20 or more (between isolated circuits) |
Number of Input/Output Points |
8 Inputs / 8 Outputs |
