| Type of Product | 2-Input AND Logic Gate, 5-Pin SC-88A |
| Maximum Operating Temperature | +125 °C |
| Input Type | CMOS |
| Country of Origin | US |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
2-Input AND Logic Gate, 5-Pin SC-88A |
Maximum Operating Temperature |
+125 °C |
Input Type |
CMOS |
Country of Origin |
US |
Length |
2.2mm |
Width |
1.35mm |
Height |
1mm |
Name of Manufacturer/Packer/Importer |
onsemi |
Dimension |
2.2 x 1.35 x 1mm |
Pack of |
Each of 1 Piece |
Package Type |
SC-88A |
Mounting Type |
Surface Mount |
Pin Count |
5 |
Minimum Operating Temperature |
-55 °C |
Output Type |
Open Drain |
Maximum Operating Supply Voltage |
5.5 V |
Minimum Operating Supply Voltage |
2 V |
No. of Elements |
1 |
Manufacturer Model Number |
MC74VHC1G09DFT2G |
Maximum Propagation Delay Time @ Maximum CL |
16.5 ns @ 50 pF |
Propagation Delay Test Condition |
50pF |
Logic Family |
VHC |
Maximum Low Level Output Current |
8mA |
Schmitt Trigger Input |
No |
Logic Function |
AND |
Number of Inputs Per Gate |
2 |
