Ships within 25 days
View
View
View
View
| Type of Product | Chip LED Indicator Light |
| Model No | ND-1-1-CHWG |
| Monotaro ID | 62648918 |
| Color | Lens color/Emitting color: W (white)/G (green) |
Type of Product |
Chip LED Indicator Light |
Model No |
ND-1-1-CHWG |
Monotaro ID |
62648918 |
Color |
Lens color/Emitting color: W (white)/G (green) |
Material |
Chrome: Brass |
Insulation Resistance |
DC500V, 100MΩ or more |
Current (mA) |
1.3 to 5.6(5V-60V) |
Withstand voltage (V) |
AC2000 (1 minute) |
RoHS Directive |
Correspondence |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Screw Tightening Torque (Nm) |
0.4 |
Name of Manufacturer/Packer/Importer |
Sato Parts Co., Ltd. |
Pack of |
1 Pcs |
Body Color |
Chrome |
Light Source |
Chip LED (protection diode built-in) / Light source color: White |
Polarity |
No connection polarity |
Insulator Material |
PBT |
Lead Wire |
UL1430 AWG24 stranded wire black (5V to 60V AC/DC) |
Suitable Door Thickness to Mount (mm) |
0 to 4 |
Panel Mounting Method |
Screw tightening |
Applicable Voltage (V) |
5 to 60 AC/DC |
