| Type of Product | Anti-static shoe leakage resistance measuring instrument |
| Model No | SHOETESTERⅡ |
| Monotaro ID | 70816017 |
| Mass (Kg) | Body: 0.9, measuring table: 4.5 |
Type of Product |
Anti-static shoe leakage resistance measuring instrument |
Model No |
SHOETESTERⅡ |
Monotaro ID |
70816017 |
Mass (Kg) |
Body: 0.9, measuring table: 4.5 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Display |
4 digits Red LED display Decimal point automatic switching |
Included Components |
Instruction manual, measuring table, wall mount fixture, ground wire, dustproof protective seal, AC adapter, measurement signal cable |
Pattern Setting |
Upper limit setting: 1, 5, 10, 20, 35, 50, 100 (MΩ) switching type, lower limit setting: 0.1, 0.5, 1, 5, 10 (MΩ) switching type |
Measurement Range |
0.00 to 200.0MΩ |
Name of Manufacturer/Packer/Importer |
Shishido Static Electricity Co., Ltd. |
Display Type |
HI lamp lights up (red) when the upper limit is exceeded, LO lamp lights up (red) when the lower limit is exceeded |
Power Supply |
DC12V (Dedicated AC adapter (OPSHT2-ADA) AC100V-240V 50 / 60Hz) |
Measurement accuracy |
±10% rdg +2% digit |
Operating Temperature (c) |
0 to 40℃ |
Dimensions, Width W x Length L x Height H (mm) |
Body: 170x140x37, measuring table: 310x350x27 |
Self-Diagnosis Function |
Self-check button Internal 1MΩ measurement is normal at 0.95 to 1.05MΩ (green display) |
Measurement Voltage (V) |
DC10 |
Measurement Modes |
Simultaneous measurement of both feet |
