| Type of Product | Triple 3-Input NAND Logic Gate, 14-Pin PDIP |
| Maximum Operating Temperature | +125 °C |
| Country of Origin | US |
| Length | 19.3mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Triple 3-Input NAND Logic Gate, 14-Pin PDIP |
Maximum Operating Temperature |
+125 °C |
Country of Origin |
US |
Length |
19.3mm |
Width |
6.35mm |
Height |
4.57mm |
Name of Manufacturer/Packer/Importer |
Texas Instruments |
Dimension |
19.3 x 6.35 x 4.57mm |
Pack of |
Each of 1 Piece |
Package Type |
PDIP |
Mounting Type |
Through Hole |
Pin Count |
14 |
Minimum Operating Temperature |
-55 °C |
Maximum Operating Supply Voltage |
18 V |
Minimum Operating Supply Voltage |
3 V |
No. of Elements |
3 |
Manufacturer Model Number |
CD4023BE |
Maximum Propagation Delay Time @ Maximum CL |
120 ns @ 10 V, 250 ns @ 5 V, 90 ns @ 15 V |
Propagation Delay Test Condition |
50pF |
Logic Family |
4000 |
Maximum Low Level Output Current |
4.2mA |
Maximum High Level Output Current |
-4.2mA |
Schmitt Trigger Input |
No |
Logic Function |
NAND |
Number of Inputs Per Gate |
3 |
