| Type of Product | Quad 2-Input NAND Schmitt Trigger Logic Gate, 14-Pin CDIP |
| Maximum Operating Temperature | +125 °C |
| Input Type | CMOS |
| Country of Origin | US |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Quad 2-Input NAND Schmitt Trigger Logic Gate, 14-Pin CDIP |
Maximum Operating Temperature |
+125 °C |
Input Type |
CMOS |
Country of Origin |
US |
Length |
19.94mm |
Width |
7.62mm |
Height |
3.56mm |
Name of Manufacturer/Packer/Importer |
Texas Instruments |
Dimension |
19.94 x 7.62 x 3.56mm |
Pack of |
Each of 1 Piece |
Package Type |
CDIP |
Mounting Type |
Through Hole |
Pin Count |
14 |
Minimum Operating Temperature |
-55 °C |
Output Type |
CMOS |
Maximum Operating Supply Voltage |
18 V |
Minimum Operating Supply Voltage |
3 V |
No. of Elements |
4 |
Manufacturer Model Number |
CD4093BF |
Maximum Propagation Delay Time @ Maximum CL |
380 ns @ 50 pF |
Propagation Delay Test Condition |
50pF |
Logic Family |
4000 |
Maximum Low Level Output Current |
4.2mA |
Maximum High Level Output Current |
-4.2mA |
Schmitt Trigger Input |
Yes |
Logic Function |
NAND |
Number of Inputs Per Gate |
2 |
