| Type of Product | Rv16 Series Potentiometer |
| Model No | RV16YN15S B302 |
| Monotaro ID | 39187574 |
| Type | Single AXIS single type |
Type of Product |
Rv16 Series Potentiometer |
Model No |
RV16YN15S B302 |
Monotaro ID |
39187574 |
Type |
Single AXIS single type |
Shape |
Panel mount type |
Diameter (Φmm) |
16.8±0.5 |
Withstand Voltage |
AC500V for 1 minute |
Operating Temperature Range |
-10 to +85°C |
Rated power (W) |
0.1(40℃), 0(85℃) |
RoHS Directive |
Correspondence |
Rotational Torque (nm) (Kgfcm) |
2 to 20[20.4 to 357] |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Contact Resistance |
(change) Less than 3% or 3Ω greater |
Included Components |
Mounting nut, toothed washer, flat washer |
Resistance |
(Residual) 3Ω or less |
Name of Manufacturer/Packer/Importer |
Tokyo Cosmos Electric Co., Ltd. |
Pack of |
1 Pcs |
Features |
(Resistance change) Linear type |
Maximum Operating Voltage |
DC200 V or rated power, whichever is smaller |
Shaft Length (mm) |
15 |
Rotation Angle |
(Electrical) 220 ± 10° (Mechanical) 260 ± 10° |
Shaft Length |
15 mm |
Insulation_Resistance (MΩ) |
100 or more (DC500V) |
Specifications |
Carbon-based |
Shaft Shape |
Groove |
Solderability |
235℃, 5sec |
