| Type of Product | Gf063 Series Single Rotation Type Cermet Trimmer |
| Model No | GF063P303 |
| Monotaro ID | 39187181 |
| Shape | Top adjustment |
Type of Product |
Gf063 Series Single Rotation Type Cermet Trimmer |
Model No |
GF063P303 |
Monotaro ID |
39187181 |
Shape |
Top adjustment |
Withstand Voltage |
900V AC for 1 minute |
Operating Temperature Range |
-55 to +125°C |
Rated power (W) |
0.5(70℃), 0(125℃) |
RoHS Directive |
Correspondence |
Rotational Torque (nm) (Kgfcm) |
0.98 to 19.6[10 to 200] |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Contact Resistance |
(Change) Less than 1% or 1Ω greater |
Strength |
(Terminal) 9.8N min [1kgf] (pulling), 3time min (90° bending) (Shaft) 9.8N min [1kgf] (push strength) |
Resistance |
(Residual) 1% or 1Ω or less |
Name of Manufacturer/Packer/Importer |
Tokyo Cosmos Electric Co., Ltd. |
Pack of |
1 Pcs |
Resistance Tolerance |
±20(±10)% |
Maximum Operating Voltage |
250 V DC or rated power, whichever is smaller |
Temperature coefficient |
(Resistance) ± 100ppm / ℃ |
Rotation Angle |
(Electrical) 210±10° (Mechanical) 250±10° |
Resistor |
cermet |
Insulation_Resistance (MΩ) |
1000 or more (500V DC) |
Nominal Resistance |
30 kΩ |
Stop Strength (mN.min [kgf.cm min]) |
49.0[0.5] |
Resistance Change Characteristics |
Linear type |
Implementation method |
Through hole |
