| Type of Product | Quad 2-Input NAND Logic Gate |
| Maximum Operating Temperature | +85 °C |
| Country of Origin | Japan |
| Length | 5.4mm |
Type of Product |
Quad 2-Input NAND Logic Gate |
Maximum Operating Temperature |
+85 °C |
Country of Origin |
Japan |
Length |
5.4mm |
Width |
4.4mm |
Height |
1mm |
Name of Manufacturer/Packer/Importer |
Toshiba |
Dimension |
5.4 x 4.4 x 1mm |
Pack of |
Each of 1 Piece |
Package Type |
TSSOP |
Mounting Type |
Surface Mount |
Pin Count |
14 |
Minimum Operating Temperature |
-40 °C |
Maximum Operating Supply Voltage |
18 V |
Minimum Operating Supply Voltage |
3 V |
No. of Elements |
4 |
Manufacturer Model Number |
TC4011BFT(N) |
Maximum Propagation Delay Time @ Maximum CL |
100 ns @ 10 V, 200 ns @ 5 V, 80 ns @ 15 V |
Propagation Delay Test Condition |
50pF |
Logic Family |
4000 |
Maximum Low Level Output Current |
4mA |
Maximum High Level Output Current |
-4mA |
Schmitt Trigger Input |
No |
Logic Function |
NAND |
Number of Inputs Per Gate |
2 |
