| Type of Product | PLC CPU Unit |
| Type | network model |
| Model No | CP2E-N14DR-D |
| Country of Origin | Japan |
Type of Product |
PLC CPU Unit |
Type |
network model |
Model No |
CP2E-N14DR-D |
Country of Origin |
Japan |
Pack of |
1 Pcs |
Monotaro ID |
58242416 |
Storage Temperature |
-20 to 75℃ (excluding battery) |
Capacity |
Program capacity 10K steps (FB program area 10K steps), data memory capacity 16K words |
Mass (g) |
335 or less |
Withstand Voltage |
There is no isolation between the DC primary power supply and DC secondary power supply. |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-20 to 60 |
Insulation Resistance (MOhm) |
There is no isolation between the DC primary power supply and DC secondary power supply. |
Power Supply |
DC power supply |
Specifications |
●Terminal block type: Fixed type (not removable) ●Grounding method: Class D grounding (Class 3 grounding) ●Overvoltage category: Category II: Corresponds to IEC61010-2-201 ●Power interruption detection time: 2 ms or more ●Output type: Relay output |
Noise Resistance |
Compliant with IEC61000-4-4 2kV (power line) |
Current Consumption (A) |
5V system 0.15, 24V system 0.05 |
Applicable Standard |
Compliant with EC directives, KC, UL, EAC |
Power Supply Voltage |
DC24 |
Input Type |
DC input |
Structure |
Built-in type in the panel |
Product |
14 points CPU unit |
EMC Standard to Conform |
Zone B |
Control |
Stored program method Combined use of cyclic scan method and one-by-one processing method (input/output control method) |
Outer Dimensions |
86x90x80 mm |
Inrush current (A) |
DC24V 30/20ms or less (at normal temperature cold start) |
Import Country |
Direct Import from Japan |
