Ships within 25 days
View
View
View
View
| Type of Product | Photomos Short Circuit Protection Non-Latch Type |
| Type | GU |
| Model No | AQV112KLAZ |
| Voltage | LED reverse voltage [VR] 5 V |
Type of Product |
Photomos Short Circuit Protection Non-Latch Type |
Type |
GU |
Model No |
AQV112KLAZ |
Voltage |
LED reverse voltage [VR] 5 V |
Country of Origin |
Japan |
Pack of |
1000 Pcs |
Monotaro ID |
73908293 |
Operating Temperature Range |
-40 to +85 |
Package / Case |
DIP6 |
Packaging Type |
Taping packaging (Z) |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Contact Configuration |
1A |
Operation Ambient Temperature (°C) |
-40 to +100 |
Terminal Shape |
Surface mount terminal |
Specifications |
Lead free |
Output Configuration |
1A |
Protective Function |
With short circuit protection (non-latch type) |
Operating Time (ms) |
2.0 (average), 5.0 (maximum) |
Import Country |
Direct Import from Japan |
Current (mA) |
LED current [IF]: 50 |
Operating current (mA) |
0.8 (average), 10 (maximum), 0.3 (recovery minimum), 0.7 (recovery average) |
Voltage Drop |
1.35 (average), 1.5 (maximum) V |
Load Current (Amp) |
Continuous: 0.5 |
Load Voltage |
60 V |
Return Time (ms) |
0.1 (average), 1.0 (maximum) |
Power dissipation (mW) |
75 (all 550) |
