Vishay Iron Powder Leaded Inductor 30 A DC Current 2 mΩ Resistance 10 μH Inductance, IHDM1008BCEV100M30

Name: Vishay Iron Powder Leaded Inductor 30 A DC Current 2 mΩ Resistance 10 μH Inductance, IHDM1008BCEV100M30
Brand: Vishay
SKU: ELE.ELE.428782290
Price: 1108 INR
Availability: InStock

Visit the Vishay Store

Available offers

Flat ₹200 off on Order above ₹7,000 | Valid for NEW Business Users

View

Flat ₹100 off on Order above ₹5000 | Valid for NEW Business Users

View

Flat ₹500 off on Order above ₹15000 | Valid for NEW Business Users

View

Flat ₹400 off on Order above ₹10,000 | Valid for REPEAT Business User

View

Features

Type of Product	Iron Powder Leaded Inductor
Height	21.75 mm
Model No	IHDM1008BCEV100M30
Dimension	25.53x20.73x21.75 mm

More Vishay Electrical Spare & Accessories products More Electrical Spare & Accessories products

Warranty as per brand

100% Original Products

Secure payments

100% Buyer protection

Top Brands

specifications

description

Type of Product	Iron Powder Leaded Inductor
Height	21.75 mm
Model No	IHDM1008BCEV100M30
Dimension	25.53x20.73x21.75 mm
Series	IHDM-1008BC-30
Length	25.53 mm
Country of Origin	China
Depth	20.73 mm
Pack of	1 Piece
Mounting Type	Through Hole
Terminal Type	Through Hole
Maximum Operating Temperature	+180°C
Minimum Operating Temperature	-40°C
Core Material	Iron Powder
DC Resistance	2 mΩ
Tolerance	±20%
Inductance	10 μH
Self Resonant Frequency	8 MHz
Name of Manufacturer/Packer/Importer	RS Components & Controls (I) Ltd
Maximum DC Current	30 A
Lead Diameter	4 mm
