| Model No | CS16A1MSW_WE |
| Type of Product | Connected Switch |
| Application | Control Switch |
| Range | Wiser |
Model No |
CS16A1MSW_WE |
Type of Product |
Connected Switch |
Application |
Control Switch |
Range |
Wiser |
Rated Current |
16 A |
Color |
White |
Country of Origin |
India |
No. of Modules |
1 |
Height |
45 mm |
Width |
22 mm |
Material |
Polycarbonate |
Mounting Type |
Flush |
Operational Voltage |
110/230 V AC, 50/60 Hz |
Finish Type |
Glossy |
Standard |
IEC 60669-2-1 |
IP Rating |
IP20 |
Connection Terminal |
Wire (phase) - 2.5 mm², Wire (neutral) - 1.5 mm² |
Name of Manufacturer/Packer/Importer |
Schneider Electric India Pvt Ltd |
Technology |
Electronic |
Installation |
Indoor Installation |
No. Of Output |
1 |
Transmission Frequency |
2.4 GHz |
Controls Type |
Push Button |
Communication Method |
Wi-Fi IEEE 802.11 |
Depth |
40 mm |
Wiring Configuration |
3 Wire |
Operating Temperature |
-5 to 45 °C |
Storage Temperature |
-5 to 45 °C |
