Dimension | 62.4 (Dia.) x 34.5mm |
Type of Product | Toroidal Transformer |
Power Rating | 15VA |
Weight | 300g |
Dimension |
62.4 (Dia.) x 34.5mm |
Type of Product |
Toroidal Transformer |
Power Rating |
15VA |
Weight |
300g |
Country of Origin |
Czech Republic |
Secondary Current |
300mA |
No. Of Output |
2 |
Secondary Voltage Rating |
2 x 25V ac |
Primary Voltage Rating |
230V ac |
Maximum Operating Frequency |
60Hz |
Maximum Temperature |
+40°C |
Diameter |
63 mm |
Termination Type |
Leads |
Height |
34.5mm |
Name of Manufacturer/Packer/Importer |
Nuvotem Talema |
Minimum Operating Frequency |
48Hz |
Manufacturer Part Number |
0015P1-2-025K |
Fixing Hole Diameter |
M5 |
