| Dimension | 18x18x15 mm |
| Type of Product | Audio Transformer |
| Power Rating | 2 mW |
| Weight | 14g |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Dimension |
18x18x15 mm |
Type of Product |
Audio Transformer |
Power Rating |
2 mW |
Weight |
14g |
Country of Origin |
Switzerland |
Mounting Type |
Through Hole |
Length |
18 mm |
Depth |
15 mm |
Width |
18 mm |
Maximum Operating Frequency |
20 kHz |
Maximum Temperature |
+75°C |
Termination Type |
PC Pin |
Isolation Voltage |
1000V |
Minimum Temperature |
-20°C |
Name of Manufacturer/Packer/Importer |
OEP |
Minimum Operating Frequency |
40 Hz |
Manufacturer Part Number |
Z1671E |
Turns Ratio |
1:1.41 C.T |
Secondary Impedance |
100Ω |
Primary Impedance |
50Ω |
Construction Type |
Enclosed |
Primary Resistance |
10.3Ω |
Core Type |
Laminated |
Product Code |
1237219 |
Secondary DC Resistance |
21.4Ω |
