Ships within 25 days
View
View
View
View
| Model No | 123-4050 |
| Type of Product | Toroidal Transformer |
| Country of Origin | Japan |
| Specifications | UL506 UL5085-1 EN61558-1 Class II EN60065 Class II. RS Pro Open Toroidal Transformer (Dual Primary Winding). RS Pro high-quality open toroidal transformer features two 115 V (50/60 Hz) primary windings. The pair of secondary windings can be connected in series, parallel or used alone. A centre hole fixing allows for easy mounting. |
Model No |
123-4050 |
Type of Product |
Toroidal Transformer |
Country of Origin |
Japan |
Specifications |
UL506 UL5085-1 EN61558-1 Class II EN60065 Class II. RS Pro Open Toroidal Transformer (Dual Primary Winding). RS Pro high-quality open toroidal transformer features two 115 V (50/60 Hz) primary windings. The pair of secondary windings can be connected in series, parallel or used alone. A centre hole fixing allows for easy mounting. |
Monotaro ID |
48530695 |
Dimension (mm) |
162(Dia.)x60 |
No. Of Output |
2 |
Name of Manufacturer/Packer/Importer |
RS Components Co., Ltd. |
Mass (g) |
5100 |
Minimum Frequency |
50 |
Maximum Frequency |
60 |
Termination Style |
Lead Wire |
Import Country |
Direct Import from Japan |
RoHS Directive |
Correspondence |
Primary Voltage (V) |
2x115 AC |
Rated Secondary Voltage (V) |
2x55 AC |
Rated Power (VA) |
800 |
Type of Sign |
Surface Mount |
