| Secondary Current (Amp) | 2.222 |
| Model No | 671-9126 |
| Type of Product | Toroidal Transformer |
| Country of Origin | Japan |
Secondary Current (Amp) |
2.222 |
Model No |
671-9126 |
Type of Product |
Toroidal Transformer |
Country of Origin |
Japan |
Specifications |
Ensure both ends of the mounting bolt do not contact the metal chassis or frame at the same time, as this could result in a dangerous winding short circuit. Mounting hardware not included (sold separately). Toroidal Open Winding, Dual, 115 V Primary. High-quality open-type toroidal transformer. Features two 115 Vac 50/60 Hz primary windings and a pair of secondary windings that can be connected in series, parallel, or used individually. Features and Benefits. Smaller and lighter than traditional laminated transformers. Ultra-low levels of radiated electromagnetic fields. Low induced noise (hum). Low core loss. Double-insulated primary leads. |
Monotaro ID |
48530363 |
Dimension (mm) |
93(Dia.)x38 |
No. Of Output |
2 |
Name of Manufacturer/Packer/Importer |
RS Components Co., Ltd. |
Mass (g) |
1000 |
Minimum Frequency |
50 |
Maximum Frequency |
60 |
Termination Style |
Copper Conductor |
Import Country |
Direct Import from Japan |
RoHS Directive |
Correspondence |
Primary Voltage (V) |
115 AC/230 AC |
Rated Secondary Voltage (V) |
2x18 AC |
Rated Power (VA) |
80 |
